ASROCK AMD B550 MOTHERBOARD MAINBOARD B550M HDV

Prev
Next

Sorry - this product is no longer available

2DDR4 4600MHz | VGA | DVI-D | HDMI | 2USB2.0 | 4USB3.2 | M-ATX
Availability: Out of stock
SKU: 4710483931635
Only available in-store
decrease increase

Products specifications
Socket AMD AM4 Socket Ryzen™ 3000, 3000 G-Series, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors
Memory 2x DIMM Slots, Max. 64GB, DDR4 4600MHz (OC)
Slot AMD Ryzen series CPUs (Vermeer and Matisse): 1x PCI Express 4.0 x16 Slot (PCIE1: x16 mode), AMD Ryzen series APUs (Cezanne and Renoir): 1x PCI Express 3.0 x16 Slot (PCIE1: x16 mode), AMD Ryzen series APUs (Picasso): 1x PCI Express 3.0 x16 Slot (PCIE1: x8 mode)
Storage Supports 4x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug; 1x Hyper M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Vermeer, Matisse) or Gen3x4 (32 Gb/s) (with Cezanne, Renoir and Picasso)
Ports & Connectors 2x USB 2.0 Ports (Supports ESD Protection), 4x USB 3.2 Gen1 Ports (Supports ESD Protection), 1x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED), 1x D-Sub Port, 1x DVI-D Port, 1x HDMI Port, 1x PS/2 Mouse/Keyboard Port, HD Audio Jacks: Line in / Front Speaker / Microphone
BIOS 256Mb AMI UEFI Legal BIOS with GUI support
Form Factor mATX Form Factor 23.0 cm x 20.1 cm
Products specifications
Socket AMD AM4 Socket Ryzen™ 3000, 3000 G-Series, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors
Memory 2x DIMM Slots, Max. 64GB, DDR4 4600MHz (OC)
Slot AMD Ryzen series CPUs (Vermeer and Matisse): 1x PCI Express 4.0 x16 Slot (PCIE1: x16 mode), AMD Ryzen series APUs (Cezanne and Renoir): 1x PCI Express 3.0 x16 Slot (PCIE1: x16 mode), AMD Ryzen series APUs (Picasso): 1x PCI Express 3.0 x16 Slot (PCIE1: x8 mode)
Storage Supports 4x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug; 1x Hyper M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Vermeer, Matisse) or Gen3x4 (32 Gb/s) (with Cezanne, Renoir and Picasso)
Ports & Connectors 2x USB 2.0 Ports (Supports ESD Protection), 4x USB 3.2 Gen1 Ports (Supports ESD Protection), 1x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED), 1x D-Sub Port, 1x DVI-D Port, 1x HDMI Port, 1x PS/2 Mouse/Keyboard Port, HD Audio Jacks: Line in / Front Speaker / Microphone
BIOS 256Mb AMI UEFI Legal BIOS with GUI support
Form Factor mATX Form Factor 23.0 cm x 20.1 cm
